NEMA Receptacle Configuration - Plugs and Receptacles
5-20R
Item - Plugs and Receptacles
GFCI Receptacle
Application Environment
Commercial
Weather Resistant - Plugs and Receptacles
No
Mounting Type - Plugs and Receptacles
Flush
Amps - Plugs and Receptacles
20 A
Standards
CSA C22.2 - 144.1 (GFCI) and 42 (Receptacles), CSA Certified, CSA Certified LR-57811, NOM Certified, UL 943 Class A (GFCI) and 498 (Receptacles), UL Listed, UL Listed E48380
Wiring Method - Plugs and Receptacles
Back and Side
Special Features
Auto-Monitoring, Custom Designed Lenses with Edge-Mounted LEDs, Dual Lens, Saves Space, Sensor Provides Automatic ON/OFF Illumination
Color - Plugs and Receptacles
Light Almond
Outlet Type - Plugs and Receptacles
Standard Duplex
Voltage - Plugs and Receptacles
125V
Additional Electrical Protections
GFCI u0026 Surge Protection
Housing Material
Thermoplastic
Resistance Properties
Tamper Resistant
Wire Connection Types
Screw Terminals
Includes Mounting Hardware
Yes
Maximum Operating Temperature
150.8 Degrees F
Key Resistance Properties
Tamper Resistant
Additional Electrical Protection
GFCI, Surge Protection
Primary Resistance Properties
Tamper Resistant - Tamper Resistant - 20 A
Market
Commercial, Residential
Number of Poles u0026 Wires
2 Pole / 3 Wire
Grade
Federal Specification
Visual Indicator Lights
Power Connected
Wire Connection Type
Screw Terminals
NEMA Receptacle Configuration
5-20R
Features
Built-In Night Light
Receptacle Type
Decorator Duplex
Minimum Operating Temperature
-31 Degrees F
Housing Color
Light Almond
Country of Origin (subject to change)
China
