Shaft Orientation
Vertical
Air Cleaner Type
Quad Clean 4 Stage Cyclonic
Recommended Use
Pressure Washer, String Trimmer, Tiller, Walk-Behind Mower
Maintenance Frequency
100 Hours/Annually Change Oil and Oil Filter, Clean Cooling Areas, Replace Fuel Filter, Clean Spark Arrestor, 300 Hours Replace Air Cleaner Element and Precleaner, Check and Replace Guide Plate, Check and Adjust Valve Clearance when Engine is Cold, Change Oil and Oil Filter (KOHLER PRO 10W-50 Oil and KOHLER PRO Filter Only), 50 Hours/Annually Service/Replace Precleaner, 500 Hours/Annually Replace Spark Plug and Set Gap, Every Use Check Oil Level, Check Air Cleaner, Check Precleaner
Shaft Configuration
Keyway
Features
3 Year Limited Commercial Warranty, Cast-Iron Cylinder Liners Add Durability and Engine Protection, Consistent-Cut(TM) Technology Maintains Engine Speed for a Cleaner Turf Cut, Even in Tall, Wet Grass, Easy Pours and Less Spilling with Accu-Fill(R) Fuel Tank's 45% Larger Angled Fuel Neck, Easy-Pull(TM) Technology, Enjoy Effortless Starts
Shaft Diameter
0.2362/0.2372 in (I.D)
Engine Series
CV224 Series
CARB Compliant
CARB Compliant
Standards
CARB Phase III, China Phase II, EPA Phase III, EU Stage V
Engine Displacement
224 cc
Country of Origin (subject to change)
United States
